Prover TESLA with 2 doors (capacity - 4 racks) for BELL 72
| Model | A4CFR |
| Power Type | Electrical |
| Power | 4 kW |
| Dimensions | 1600x1420x2000+280 mm |
| Voltage | 380V |
Structure composed of expanded polyurethane panels covered with aluminum plate. Prepainted aluminum door with glass porthole (with right/left hinges) – specify in the order. Digital control panel with multifunction rotary switch with 30 programs settings and programmable daily/weekly start. Automatic thermoregulation of temperature. Humidity automatic control. Upper heat and steam generators of new generation, outside the prover. Recycle fan. Inner lighting. Electrical connection: cable 5x2,5 mm2. Water connection: from ¾” with pipe of ½”. Water average consumption per hour: 2/3 Liter/H. Water pressure: min. 1 Bar. , Max 3 Bar. Water flow: from 1 to 1,5 Liter/Min. Max water hardness: from 15 to 20 °F. Provers having 2 front doors are supplied with a central tie bar to give a better solidity to the whole structure. It is possible to order provers without tie bar but in this case tightness between the doors will be clearly lower.
